Salient Features
- Spheroidal Graphite (SG) Iron Body
- Chrome Plated Steel Spindle & Handle
- Hardened & Tempered C38 Carbon Steel Jaws
- Robust design and construction
- Conforms to (DIN) PA 80-3.5.2/03.07
Note: While the inherent toughness, durability and advantages of a Steel Vice over a Gray Cast Iron Vice are well known, Spheroidal / Nodular Graphite (SG) Iron, too, is stronger, more durable and has distinct advantages over Gray Cast Iron in that it has a
- Higher Tensile strength
- High ductility and toughness
- High resistance to wear & tear and corrosion
Specifications
| Size (mm) | Size (inches) | Length of Jaw (L) (mm) | Opening of Jaw (O) (mm) | Jaw Dimension (mm) | Height of Jaw (H) (mm) | Packing per Carton (Pcs.) | Weight per Carton (Kgs.) (Fixed Base) | Weight per Carton (Kgs.) (Swivel Base) |
|---|---|---|---|---|---|---|---|---|
| 100 | 4 | 100 | 115 | 100 x 10 x 18 | 60 | 2 | 17 | 18 |
| 125 | 5 | 125 | 135 | 125 x 12 x 23 | 70 | 1 | 13 | 14 |
| 150 | 6 | 150 | 165 | 150 x 12 x 23 | 80 | 1 | 18 | 20 |
| 180 | 7 | 180 | 210 | 180 x 12 x 23 | 134 | 1 | 24 | 27 |
